CD4093 Schmitt Trigger IC

Quad NAND Gates: The CD4093 contains four identical NAND gates, each with two inputs (A and B) and one output (Y). These NAND gates can be used for a variety of digital logic functions.

Schmitt Trigger Inputs: The CD4093 features Schmitt trigger inputs, which have hysteresis. This means that the input signal must cross a higher threshold to switch the output from high to low and a lower threshold to switch it from low to high. Schmitt triggers are useful in applications where noise or signal jitter needs to be filtered out.

Power Supply Voltage: The CD4093 typically operates with a power supply voltage in the range of 3 volts to 15 volts, making it compatible with various digital systems.

Low Power Consumption: It has low power consumption, making it suitable for battery-powered and low-power electronics.

Applications: The CD4093 is commonly used in applications where logical NAND operations with Schmitt trigger inputs are required. It is used in signal conditioning, pulse shaping, oscillator circuits, and various digital logic circuits.
